Chapter 1 7
Bottom Panel
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery lock Locks the battery in position.
3 Hard disk bay Houses the computer's hard disk (secured with screws).
4 Memory compartment Houses the computer's main memory.
5 Battery release latch Releases the battery for removal.
