Removing the LED Indicators Board
1. See “Removing the Battery Pack” on page 51.
2. See “Removing the Lower Cover” on page 51.
3. See “Removing the Lower Cover” on page 51.
4. See “Removing the Fan Module” on page 59.
5. See “Removing the CPU Heatsink Module” on page 60.
6. See “Removing the CPU” on page 61.
7. See “Removing the Middle Cover” on page 62.
8. See “Removing the Keyboard” on page 63.
9. See “Removing the LCD Module” on page 64.
10. See “Separating the Upper Case from the Lower Case” on page 68.
11. Remove the screw (G) on the LED indicators board.
12. Turn the LED board over, then detach the LED cable from the board.
13. Disconnect the LED board cable from the board, then remove the board.
Step Size (Quantity) Color Torque
1 M2 x L3 (1) Silver 1.6 kgf-cm
