Chapter 3 63
Removing the Keyboard
1. See “Removing the Battery Pack” on page 51.
2. See “Removing the Middle Cover” on page 62.
3. Remove the two screws (G) securing the keyboard.
4. Carefully pry up and out the keyboard and turn it over.
Step Size (Quantity) Color Torque
1-2 M2 x L3 (2) Silver 1.6 kgf-cm
To Next Page
