eMachines D620 - Lcd Module Disassembly Process; Lcd Module Disassembly Flowchart

76 Chapter 3
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Main Screw List
Item Screw Part No.
C M2 x L3 86.9A552.3R0
E M2.5 x L6 86.00E33.736
H M2.5 x L5 86.00F87.735
I M2.5 x L5 86.00F00.735
LCD MODULE
LCD BEZEL
LEFT HINGE
RIGHT HINGE
Ex2, Hx4
Ix1
Ix1
LCD ASSEMBLY
LEFT LCD
BRACKET
Cx4
RIGHT LCD
BRACKET
Cx4
CCD
BOARD
INVERTER BOARD
LCD BACK PANEL
AUXILIARY
ANTENNA
MICROPHONE
LCD MODULE DISASSEMBLY
Hx1
Ix2
LCD FPC
CABLE
MAIN
ANTENNA
