EMC-PARTNER ESD3000 - Discharge Module ESD3000 DM6 (IEC 61340-3-1, JEDEC 22-A114, MIL-STD-750 D9); Discharge Module ESD3000 DM7 (IEC 61340-3-2, JEDEC 22-A115); Discharge Module ESD3000 DM8 (IEC 60571, en 50155)

ESD3000-System
10/66
1.2.6 Discharge Module ESD3000DM6 (IEC 61340-3-1, JEDEC 22-A114, MIL-STD-750D9)
Energy storage capacitance 100 pF ± 10%
Discharge resistance
1500 Ω
± 10%
Discharge mode only contact discharge
Current rise time, 50 Ω load
2 to 10 ns
RC time constant 150 ns
Voltage range 200 V up to 10000 V
Voltage rise time, 500 Ω load
5 to 25 ns
Voltage verification V charging1000V 375 up to 550 V
Voltage range 200 V up to 8000 V
1.2.7 Discharge Module ESD3000DM7 (IEC 61340-3-2, JEDEC 22-A115)
Energy storage capacitance 200 pF ± 10%
Discharge resistance
500 Ω
± 10%
Discharge mode only contact discharge
Current waveform, short circuit <1 Ω
First peak to second peak 67% to 97%
oscillation period 63 ns up to 91 ns
Voltage verification V charging 400V first peak <1.31 A
Voltage verification V charging 400V amplitude at 100 ns 0.29 A -15%
Voltage range 80 V up to 2500 V
1.2.8 Discharge Module ESD3000DM8 (IEC 60571, EN 50155)
Waveform B Risetime 10/90% < 0.05 µs
Half value time 50 % to 50%
0.1 µs ± 20%
Voltage amplitude > 8400 V
Series Resistor (Rs)
100Ω ± 10%
Dimension / Weight l = 120, diameter = 60 mm 0.5 kg
Pulse Repetition Maximum 1 Hz
Required equipment ESD3000 + DM8
Voltage amplitude CD 200V up to 10’000V CD = Contact Discharge
Further Information to additional discharge modules DM or discharge networks DN can be
found in the relevant instruction sheets. or in the ESD3000 brochure.
