12 Modules and accessories
12.1 ESD3000 with DM discharge modules
Pos. Product No. Type Short Description
103606 ESD3000DM1 Discharge module IEC 61000-4-2, 150pF, 330 Ohm, AD up to
16kV, CD up to 10kV.
Incl.
. 1 rounded tip for AD
. 1 sharp tip for CD
103607 ESD3000DM2 Discharge module ISO TR10605, 330pF, 2000 Ohm, AD up to
16kV, CD up to 10kV (inside vehicle).
Incl.
. 1 rounded tip for AD
. 1 sharp tip for CD
103608 ESD3000DM4 Discharge module MIL 883 and GR-78-CORE 100pF, 1500
Ohm, CD up to 10kV, AD up to 16kV.
Incl.
. 1 sharp tip for CD
. 1 rounded tip for AD
. 1x 0.75m cable green-yellow
. 1 ESD-MC plug blue
103609 ESD3000DM5 Discharge module RTCA/DO160-D, 150pF, 330 Ohm, AD up
to 30kV consisting of ESD3000DM5+ and ESD3000DM5-.
Incl.
. 2 rounded tips for AD
103610 ESD3000DM6 Discharge Module IEC 61340-3-1, 100pF, 1500 Ohm, CD up
to 8kV.
Incl.
. 1 sharp tip for CD
103611 ESD3000DM7 Discharge Module IEC 61340-3-1, 200pF, 0 Ohm, CD up to
3kV.
Incl.
. 1 sharp tip for CD
103612 ESD3000DM8 Discharge Module in accordance with IEC 60571 and EN
50155 for Railway Testing
