ESD3000- System
46/66
Pos. Product No. Type Short Description
103625 ESD3000RM32
Relay module with high voltage and polarity switch. Circuit for
generating the first current peak. Can be used for CD up to
30kV and AD up to 30kV. Minimum one DN must be added.
Incl.
. 1 rounded tip for AD
. 1 sharp tip for CD
. 1 electrode 30mm
. 1 permanent magnet.
103615 ESD3000DN1 Discharge Network according to IEC 61000-4-2 with capacitor
150pF and resistor 330 Ohm. AD from 1kV up to 30kV and CD
from 1kV up to 30kV.
103616 ESD3000DN2 Discharge Network according to ISO TR10605 with capacitor
330pF and resistor 2000 Ohm. AD from 1kV up to 30kV and
CD from 1kV up to 30kV.
103617 ESD3000DN3 Discharge Network according to ISO TR10605 with capacitor
150pF and resistor 2000 Ohm. AD from 1kV up to 30kV and
CD from 1kV up to 30kV.
103618 ESD3000DN4
For explosive device testing MIL-STD-1512 or VG95378 with
capacitor 500pF and resistor 5000 Ohm. AD from 1kV up to
30kV and CD from 1kV up to 30 kV.
Consisting of 1 discharge network. ESD3000DM-EXT and
safety switch must be ordered separately.
103619 ESD3000DN5
Discharge network for military testing according to
MIL-STD-331, MIL-DTL-23659D or STANAG 4239. 500pF,
500 Ohm.
AD and CD 2kV up to 30kV. Requires ESD3000RM32.
ESD3000DM-EXT & safety switch can be ordered separately
104126 ESD3000DN6
Discharge network for automotive testing according to ISO
TR 10605. VW TL 824-66 and Daimler Chrysler DC 10614.
330pF, 330 Ohm. AD and CD 2kV up to 30kV. Requires
ESD3000RM32.
