ESD3000-System
9/66
1.2.3 Discharge Module ESD3000DM2 (ISO TR10605 - inside vehicle, module tests)
Energy storage capacitance 330 pF ± 10%
Discharge resistance
2000 Ω
± 10%
Holding time (drop to 95%) better than 5 s
Current rise time, 2 Ω load
0,7 to 1 ns
First current amplitude into 2 Ω
„contact discharge“
7,5 to 30 A ± 10%
RC time constant 600 ±130ns
Voltage range „air discharge“ 0.2 to 16 kV ± 10%
Voltage range „contact discharge“ 0.2 to 10 kV ± 10%
1.2.4 Discharge Module ESD3000DM4 (MIL-STD-883E, MIL-STD-464, GR78-CORE)
Energy storage capacitance 100 pF ± 10%
Discharge resistance
1500 Ω
± 10%
Holding time (drop to 95%) better than 5 s
Current rise time, 2 Ω load
<10 ns at - 4 kV
Peak current 3.33 A at 5 kV
Voltage range „air discharge“ 0.2 to 16 kV ± 10%
Voltage range „contact discharge“ 0.2 to 10 kV ± 10%
1.2.5 Discharge Module ESD3000DM5 (RTCA/DO 160)
Energy storage capacitance 150 pF ± 10%
Discharge resistance
330 Ω
± 10%
Holding time (drop to 95%) better than 5 s
Current rise time, 2 Ω load
<5 ns at 15 kV
RC time constant 50 ns
Voltage setting accuracy ± 10% for voltages greater than 5 kV and ±
500 V for voltages lower than 5 kV
Voltage range „contact discharge“ 1 to 30 kV ± 10%
