EMC-PARTNER ESD3000 - 1.3 Technical Data: ESD3000 RM and DN Networks

ESD3000-System
11/66
1.3 Technical data of the ESD3000RM and DN Discharge Networks
For all DN network the ESD3000RM relay module is necessary.
Discharge network ESD3000DN1 (IEC 61000-4-2 and EN61000-4-2)
Energy storage capacitance 150 pF ± 10%
Discharge resistance
330 Ω
± 10%
Charging resistance
54 MΩ
Holding time (drop to 95%) better than 5 s
Current rise time, 2 Ω load
0,7 to 1 ns
First current amplitude into 2 Ω
„contact discharge“
7,5 to 30 A ± 10%
Current amplitude at 30 ns 4 to 16 A ± 30%
Current amplitude at 60 ns 2 to 8 A ± 30%
Voltage range „air discharge“ 1 to 30 kV ± 10%
Voltage range „contact discharge“ 1 to 30 kV ± 10%
1.3.1 Discharge Network ESD3000DN2 (ISO TR10605 - inside vehicle, module tests)
Energy storage capacitance 330 pF ± 10%
Discharge resistance
2000 Ω
± 10%
Holding time (drop to 95%) better than 5 s
Current rise time, 2 Ω load
0,7 to 1 ns
First current amplitude into 2 Ω
„contact discharge“
7,5 to 30 A ± 10%
RC time constant 600 ±130ns
Voltage range „air discharge“ 1 to 30 kV ± 10%
Voltage range „contact discharge“ 1 to 30 kV ± 10%
1.3.2 Discharge network ESD3000DN3 (ISO TR10605 -outside vehicle, sensitive classification)
Energy storage capacitance 150 pF ± 10%
Discharge resistance
2000 Ω
± 10%
Holding time (drop to 95%) better than 5 s
Current rise time, 2 Ω load
5 ns at + 15 kV
RC time constant 300 ±60ns
Voltage range „air discharge“ 1 to 30 kV ± 10%
Voltage range „contact discharge“ 1 to 30 kV ± 10%
