ESD3000-System
12/66
1.3.3 Discharge Module ESD3000DN4 (MIL-STD-883E, MIL-STD-464, GR78-CORE)
Technical data
Voltage contact up to 30 kV
Capacitance DN4 500 pF
Serial resistor DN4 5000 Ohm
Weight incl. accessories 0.8 kg
Standard MIL-STD 1512
Standard VG 95378
Usable with testers ESD3000, ESD3000RM32
1.3.4 Discharge Module ESD3000DN5 (MIL-DLT-23659D, STANAG 4239, MIL-STD 331)
Technical data
Voltage contact up to 30 kV
Capacitance 500 pF
Serial resistor 500 Ohm
Weight incl. accessories 0.8 kg
Standard customised
Usable with testers ESD3000, ESD3000RM32
1.3.5 Discharge Module ESD3000DN6 (MIL-DLT-23659D, STANAG 4239, MIL-STD 331)
Technical data
Energy storage capacitance 330 pF ± 10%
Discharge resistance
330 Ω
± 10%
Charging resistance
54 MΩ
Holding time (drop to 95%) better than 5 s
Current rise time, 2 Ω load
0,7 to 1 ns
Voltage range „contact discharge“ 1 to 30 kV ± 10%
First current amplitude into 2 Ω „air
discharge“
< 5ns
RC time constant 300 ns ± 60ns
Voltage range „air discharge“ 1 to 30 kV ± 10%
Further Information to additional discharge modules DM or discharge networks DN can be
found in the relevant instruction sheets. or in the ESD3000 brochure.
