14 ESD3000 Control with Test-Manager (Tema)
14.1 Remote Control from PC
Direct control of the ESD3000 with a PC requires the following items:
− ESD-OPTOLINK (RS232-interface with 10m optical wire)
− ESD-TRA-CABLE (cable with LEMO plugs to connect interface and ESD3000)
− TEMA (‘Test-Manager’ software)
Test-Manager software is available for all EMC Partner generators and enables complex test sequences to
be programmed using standard windows methods. Test reports can be generated which include results
from different generator sources and pictures from a DSO (Digital Storage Oscilloscopes).
ESD3000 can be connected directly to a PC and benefits from all these features.
When TEMA software is started, the following window appears:
