EMC-PARTNER ESD3000 - Page 47

ESD3000-System
47/66
Pos. Product No. Type Short Description
103627 ESD-
OPTOLINK
Optical link to control ESD3000 from PC. Must be ordered together
with TEMA. Optolink length 10 m with special LEMO plug and
RS232 9 pin connector. Incl. 1x ESD-TRA-CABLE
103630 ESD-
TARGET2
2 Ohm Target with SMA connector, upper limit >4GHz. For ESD
calibration verification and comparison. Calibrated target attenuator
cable chain.
Incl.
- 1x cable 50 Ohm
103629 ESD-VERI-V Charging voltage (up to 25kV) measurement divider 20Gohm, ratio
determined by the 1Mohm input of the oscilloscope. Ratio approx.
1:20'000. Incl MC banana plugged cable green/yellow (1x 0.80m).
103485 ESD-VCP50 Vertical coupling plate 0.5 x 0.5m with 2m cable and 2 x 470kOhm
resistors.
103637 ESD-STAND
Ed2
Non metallic stand for ESD MOUSE, ESD2000, ESD3000
ESD3000DM-EXT, in accordance with IEC 61000-4-2 Ed.2
103634 CNH12 Accessory to ESD3000 with RM32 and DN1 to simulate rapidly
changing H-field as generated at real ESD discharge.
103628 ESD3000DM-
EXT
Accessory to ESD3000DM's to separate the control and the
discharge module for special applications like airbag or explosive
device testing. With the ESD3000DM-EXT the control can be
separated maximum 1m.
103626 ESD3000
SAFETY-
SWITCH
Safety switch to short circuit the ESD3000 output, when testing
explosive devices. Must be used together with ESD3000DN4 and
ESD3000RM32.
