Emerson 8800C User Manual

A-17
Reference Data
ORDERING INFORMATION
Model Product Description
8800C Vortex Flowmeter
8800A Vortex Flowmeter, Hastelloy© wafer meters only
Code Meter Style
W Wafer style
F Flanged style
D Dual-sensor style (Flanged style only)
Code Line Size
005
1
/2 Inch (15 mm)
010 1 Inch (25 mm)
015 1
1
/2 Inches (40 mm)
020 2 Inches (50 mm)
030 3 Inches (80 mm)
040 4 Inches (100 mm)
060 6 Inches (150 mm)
080 8 Inches (200 mm)
100 10 Inches (250mm)
120 12 Inches (300mm)
Code Wetted Materials
S 316L wrought stainless and CF-3M cast stainless
H
(1)
C-22
®
and C-276 wrought Hastelloy
®
; CX2MW and CW12MW cast Hastelloy
®
Code Flange or Alignment Ring Size
A1 ASME B16.5 (ANSI) RF Class 150
A3 ASME B16.5 (ANSI) RF Class 300
A6 ASME B16.5 (ANSI) RF Class 600
A7
(2)
ASME B16.5 (ANSI) RF Class 900
B1 ASME B16.5 (ANSI) RTJ Class 150 for flange-style only
B3 ASME B16.5 (ANSI) RTJ Class 300 for flange-style only
B6 ASME B16.5 (ANSI) RTJ Class 600 for flange-style only
B7
(2)
ASME B16.5 (ANSI) RTJ Class 900 for flange-style only
C1 ASME B16.5 (ANSI) RF Class 150, smooth finish
C3 ASME B16.5 (ANSI) RF Class 300, smooth finish
C6 ASME B16.5 (ANSI) RF Class 600, smooth finish
C7
(2)
ASME B16.5 (ANSI) RF Class 900, smooth finish
D0 DIN PN 10 2526-Type D
D1 DIN PN 16 (PN 10/16 for wafer-style)2526-Type D
D2 DIN PN 25 2526-Type D
D3 DIN PN 40 (PN 25/40 for wafer-style) 2526-Type D
D4 DIN PN 64 2526-Type D
D6
(3)
DIN PN 100 2526-Type D
D7
(2)
DIN PN 160 2526-Type D
G0 DIN PN 10 2512-Type N for flange-style only
G1 DIN PN 16 2512-Type N for flange-style only
G2 DIN PN 25 2512-Type N for flange-style only
G3 DIN PN 40 2512-Type N for flange-style only
G4 DIN PN 64 2512-Type N for flange-style only
G6 DIN PN 100 2512-Type N for flange-style only
G7
(2)
DIN PN 160 2512-Type N for flange-style only
Continued on Next Page
