Rosemount Model 8800C Vortex Flowmeter
3-6
PV Units The Model 8800C flowmeter displays Volumetric, Mass, STD/Normal,
Velocity, or Special units as determined by your application. Use the
Process Variable Units (PV) function to select the units for your
application and needs.
NOTE
After changing flow units, be sure to send data to the transmitter so that
the associated variables (4–20 mA points, etc.) will be recalculated by the
microprocessor. The Model 8800C recalculates all variables that depend
on units. You may then change any of the remaining parameters.
The following flow unit options are available:
Volumetric Units
Volumetric Units (1 bbl = 42 gal)
Mass Units
Mass Flow Units
If you select a Mass Units option, you must enter process density in
your configuration. (1 ston = 2000 lb; 1 ton = 1000 kg)
HART Comm. 1, 3, 3
HART Comm.
1, 3, 3, 1
gal/s impgal/s
gal/min impgal/min
gal/h impgal/h
gal/d impgal/d
ACFM L/s
ACFH L/min
ACFD L/h
bbl/min L/d
bbl/h ACMM
bbl/d ACMH
ACMD
MACMD
HART Comm. 1, 3, 3, 2, 1
lb/s ston/h
lb/min ston/d
lb/h met ton/h
lb/d met ton/d
kg/s
kg/min
kg/h
kg/d
To Next Page
