Rosemount Model 8800C Vortex Flowmeter
C-4
Figure C-2. HART Communicator Menu Tree for Model 8800*
1 DEVICE SETUP
2 PV
3 AO
4 LRV
5 URV
1 Process Variable
2 PV Percent Range
3 Analog Output
4 Vortex Frequency
5 Pulse Output
6 Total
1 M
EASURING ELEMENTS
2 SIGNAL CONDITIONING
3 OUTPUT CONDITIONING
4 DEVICE INFO
1 PROCESS
VARIABLES
2 DIAGNOSTICS
AND SERVICE
3 BASIC SETUP
4 DETAILED
SETUP
5 REVIEW
1 T
EST DEVICE
2 Loop Test
3 C
ALIBRATION
NOTE
The Review menu
lists all of the
information stored
in the Model 8800C,
including device
information, signal
condition, output
condition, and
software revision
1 Flow Units
2 Tag
3 Range Values
4 D
EVICE INFO
1 Line Size
2 K-Factor
3 Service Type
4 Pipe Inside Diameter
5 PV Sensor S/N
6 Meter Body Serial
7 Final Assembly Number
1 Self Test
2 Status
1 Manufacturer
2 Tag
3 Descriptor
4 Message
5 Date
6 Device ID
7 Write Protect
8 C
ONSTRUCTION MATERIALS
9 REVISION NUMBERS
1 Flange Type
2 Wetted Material
3 Spool Body Type
1 PROCESS VARIABLES
2 FLOW UNITS
3 METER CONFIGURATION
4 SENSOR
5 CALIBRATION
6 TEST DEVICE
1 Volume Unit
2 Base Volume Unit
3 Conversion
4 Base Time Unit
5 Flow Rate Unit
1 Dialog-to-Analog Trim
2 Scaled D/A Trim
1 Flow Units
2 S
PECIAL UNITS
3 Process Density
1 SENSOR CORRECTION
2 Lower Sensor Limit
3 Upper Sensor Limit
4 Minimum Span
5 Range Values
6 PV Sensor S/N
1 PROCESS VARIABLES
2 Range Values
3 Flow Units
4 C
ALIBRATION
5 S
IGNAL PROCESSING
1 Dialog-to-Analog Trim
2 Scaled D/A Trim
1 Self Test
2 Status
1 Filter Restore
2 Low Flow Cutoff
3 Low Pass Filter
4 Trigger Level
5 Filter Tracking
1 Process Variables
2 PV Percent Range
3 Analog Output
4 Vortex Frequency
5 Pulse Output
6 Total
1 PROCESS VARIABLES
2 Damping Values
3 A
NALOG OUTPUT
4 PULSE OUTPUT
5 TOTALIZER
6 HART OUTPUT
7 Local Display
8 Loop Test
1 Process Variables
2 PV Percent Range
3 Analog Output
4 Vortex Frequency
5 Pulse Output
6 Total
1 Analog Output
2 AO Alarm Type
3 Loop Test
4 C
ALIBRATION
1 Pulse Output
2 Pulse Output Mode
3 Pulse Output Test
1 Total
2 Pulse Output
3 Totalizer Control
1 Process Temp
2 Pipe ID
3 Wetted Material
4 Spool Body
1 Poll Address
2 Number Req Preams
3 Burst Mode
