Rosemount Model 8800C Vortex Flowmeter
2-16
Table 2-7. Flanged-Style Flowmeter (
1
/2-through 3-in./ 15 through 80 mm Line Sizes)
Nominal Size
Inch (mm)
Flange
Rating
Face-to-face A
Inch (mm)
(1)
A-ANSI RTJ
Inch (mm)
Diameter B
Inch (mm)
(2)
C
Inch (mm)
(3)
Weight
(4)
lb (kg)
½ (15) Class 150
Class 300
Class 600
6.9 (175)
7.2 (183)
7.7 (196)
–
7.7 (196)
7.7 (196)
0.52 (13,2)
0.52 (13,2)
0.52 (13,2)
7.6 (193)
7.6 (193)
7.6 (193)
9.1 (4,1)
10.4 (4,7)
10.8 (4,9)
PN 16/40
PN 100
6.1 (155)
6.6 (168)
–
–
0.52 (13,2)
0.52 (13,2)
7.6 (193)
7.6 (193)
10.4 (4,7)
12.3 (5,6)
JIS 10K/20K
JIS 40K
6.3 (160)
7.3 (185)
–
–
0.52 (13,2)
0.52 (13,2)
7.6 (193)
7.6 (193)
10.1 (4,5)
13.5 (6,1)
1 (25) Class 150
Class 300
Class 600
Class 900
7.5 (191)
8.0 (203)
8.5 (216)
9.4 (239)
8.0 (203)
8.5 (216)
8.5 (216)
9.4 (239)
0.95 (24,1)
0.95 (24,1)
0.95 (24,1)
0.95 (24,1)
7.7 (196)
7.7 (196)
7.7 (196)
7.7 (196)
12.3 (5,6)
15.0 (6,8)
15.8 (7,2)
24.3 (11,0)
PN 16/40
PN 100
PN 160
6.3 (160)
7.7 (195)
7.7 (195)
–
–
–
0.95 (24,1)
0.95 (24,1)
0.95 (24,1)
7.7 (196)
7.7 (196)
7.7 (196)
13.5 (6,1)
19.5 (8,8)
19.5 (8,8)
JIS 10K/20K
JIS 40K
6.5 (165)
7.9 (200)
–
–
0.95 (24,1)
0.95 (24,1)
7.7 (196)
7.7 (196)
13.7 (6,2)
17.4 (7,9)
1 ½ (40) Class 150
Class 300
Class 600
Class 900
8.2 (208)
8.7 (221)
9.4 (239)
10.4 (264)
8.7 (221)
9.2 (234)
9.4 (239)
10.4 (264)
1.49 (37,8)
1.49 (37,8)
1.49 (37,8)
1.49 (37,8)
8.1 (206)
8.1 (206)
8.1 (206)
8.1 (206)
17.6 (8,0)
23.0 (10,4)
25.3 (11,5)
36.3 (16,5)
PN 16/40
PN 100
PN 160
6.9 (175)
8.2 (208)
8.4 (213)
–
–
–
1.49 (37,8)
1.49 (37,8)
1.49 (37,8)
8.1 (206)
8.1 (206)
8.1 (206)
19.3 (8,8)
27.9 (12,7)
29.3 (13,3)
JIS 10K/20K
JIS 40K
7.3 (185)
8.5 (215)
–
–
1.49 (37,8)
1.49 (37,8)
8.1 (206)
8.1 (206)
18.6 (8,4)
25.6 (11,6)
2 (50) Class 150
Class 300
Class 600
Class 900
9.3 (236)
9.8 (249)
10.5 (267)
12.8 (325)
9.8 (249)
10.4 (264)
10.7 (271)
12.9 (328)
1.92 (48,8)
1.92 (48,8)
1.92 (48,8)
1.92 (48,8)
8.5 (216)
8.5 (216)
8.5 (216)
8.5 (216)
22.0 (10,0)
26.0 (11,8)
29.6 (13,4)
59.4 (26,9)
PN 16/40
PN 64
PN 100
PN 160
8.0 (203)
9.2 (234)
9.6 (244)
10.2 (259)
–
–
–
–
1.92 (48,8)
1.92 (48,8)
1.92 (48,8)
1.92 (48,8)
8.5 (216)
8.5 (216)
8.5 (216)
8.5 (216)
23.0 (10,4)
30.6 (13,9)
36.4 (16,5)
38.7 (17,6)
JIS 10K
JIS 20K
JIS 40K
7.7 (195)
8.3 (210)
9.8 (249)
–
–
–
1.92 (48,8)
1.92 (48,8)
1.92 (48,8)
8.5 (216)
8.5 (216)
8.5 (216)
19.5 (8,8)
20.1 (9,1)
28.3 (12,8)
3 (80) Class 150
Class 300
Class 600
Class 900
9.9 (251)
10.6 (269)
11.4 (290)
12.9 (328)
10.4 (264)
11.2 (284)
11.5 (292)
13.0 (330)
2.87 (72,9)
2.87 (72,9)
2.87 (72,9)
2.87 (72,9)
9.1 (231)
9.1 (231)
9.1 (231)
9.1 (231)
36.9 (16,7)
46.1 (20,9)
52.1 (26,6)
75.5 (34,2)
PN 16/40
PN 64
PN 100
PN 160
8.9 (226)
10.0 (254)
10.5 (267)
11.2 (284)
–
–
–
–
2.87 (72,9)
2.87 (72,9)
2.87 (72,9)
2.87 (72,9)
9.1 (231)
9.1 (231)
9.1 (231)
9.1 (231)
36.3 (16,5)
45.1 (20,5)
54.4 (24,7)
59.6 (27,0)
JIS 10K
JIS 20K
JIS 40K
7.9 (200)
9.3 (235)
11.0 (280)
–
–
–
2.87 (72,9)
2.87 (72,9)
2.87 (72,9)
9.1 (231)
9.1 (231)
9.1 (231)
27.6 (12,5)
35.0 (15,9)
50.0 (22,7)
(1) ±0.14 inch (3.6 mm)
(2) ±0.03 inch (0.8 mm)
(3) ±0.20 inch (5.1 mm)
(4) Add 0.2 lb (0,1 kg) for display option.
