3-13
Operation
Meter Body Number
Meter Body Number is a factory set configuration variable that
stores the body number of your particular flowmeter and the type
of construction. The meter body number is found to the right of the
body number on the meter body tag, which is attached to the support
tube of the meter body.
The format of this variable is a number followed by an alpha numeric
character. The number designates the body number. The alpha numeric
character designates the meter body type. There are three options for
the alpha numeric character:
1. None – Indicates welded meter construction
2. A – Indicates welded meter construction
3. B – Indicates cast construction
Flange Type
Flange Type enables you to specify the type of flange on the flowmeter
for later reference. This variable is preset at the factory but can be
changed if necessary.
• Wafer
• ASME B16.5 (ANSI) 150
• ASME B16.5 (ANSI) 300
• ASME B16.5 (ANSI) 600
• ASME B16.5 (ANSI) 900
• PN 10
• PN 16
• PN 25
• PN 40
• PN 64
• PN 100
• PN 160
• JIS 10k
• JIS 20k
• JIS 40k
• Special
Installation Effect
Installation Effect enables you to compensate the flowmeter for
installation effects. See reference graphs located in Technical Data
Sheet 00816-0100-3250 for the percent of K-factor shift based on
entrance effects of upstream disturbances. This value is entered as a
percentage of the range of +1.5% to -1.5%.
HART Comm. 1, 4, 1, 4
HART Comm. 1, 4, 1, 5
HART Comm. 1, 4, 1, 6
