Chapter 3 – I/O Modules
This chapter discusses the placement and wiring for I/O modules in the
ControlWave. The chapter begins with some general instructions on
module installation and wiring guidelines that are common to most I/O
modules. The balance of the chapter includes specific details for
configuring and wiring each type of I/O module.
In This Chapter
3.1 ...........................................................................3-3 Module Placement
3.2
.....................................................................................3-4 Status LEDs
3.3
...............................................................................................3-4 Wiring
3.2.1
.................................................................3-5 Local Termination
3.2.2
.............................................................3-6 Remote Termination
3.2.3
......................................................3-6 Shielding and Grounding
3.4
................................................................3-8 Digital Input (DI) Modules
3.5
.........................................................3-13 Digital Output (DO) Modules
3.6
.............................................................3-19 Analog Input (AI) Modules
3.7
........................................................3-24 Analog Output (AO) Modules
3.8
...........................................3-29 Universal Digital Input (UDI) Modules
3.9
.....3-35 Isolated Resistance Temperature Device (RTD) Input Module
3.10
............................3-39 Isolated Low Level Analog Input (LLAI) Module
Installation
Installing any I/O module in the ControlWave involves the same basic
steps:
1. Remove the I/O module from the shipping carton. I/O modules
include a removable terminal housing assembly. This assembly has
a door that swings downward to provide access to the unit’s terminal
handle you can use to remove an installed I/O module once you
loosen the captured panel fasteners.
Note: Modules normally ship from the factory completely
assembled.
2. Turn the terminal block’s quarter turn fasteners (counterclockwise)
and remove the terminal housing assembly from the I/O module (see
Figure 3-1).
3. Wire the modules according to instructions for each individual
module, included later in this chapter. I/O modules support local
terminations (field wiring connected directly to the I/O module’s
terminal block PCB) or remote terminations (field wiring connected
to a remote DIN-rail mounted terminal block assembly). See Section
3.2.1 for information on local termination wiring and Section 3.2.2
for information on remote termination wiring.
4. Align the I/O module with the assigned I/O slot and gently push the
module into the chassis. When the assembly is fully seated, turn the
I/O module’s captured panel fasteners (clockwise) to secure the unit
