ControlWave Instruction Manual (CI-ControlWave)
Revised Nov-2010 Service & Troubleshooting 5-25
Table 5-4. Port 80 Run Time Status Codes
HEX
Code
Definition Notes
00 No Application
01 Application Loaded
10 Application Loaded - BPTs Set Break Point(s) Set
11 Application Running Display Blank
12 Running with BPT Break Point in Debug
1D Currently Loading the Boot Project
51 System Initialization in Progress
86 Recovery Mode SW3-3 = ON; during
normal runtime operation
you should set SW3-3 to
OFF.
BA Standby (redundant systems only) Valid Standby
(can take over)
BC Standby (redundant systems only) Connected to Master
BD Standby (redundant systems only) Not Connected to
Master
BF Battery Fail Check S3-4
CA Hot Card Replacement in Progress
CF Invalid Checksum Detected Unit Stopped
D0 Diagnostic Mode SW1-8 =OFF
D1 Running Diagnostic
DE User Application has failed to start Invalid I/O Card
configuration
F0 NPX Error Unit Stopped
F1 Waiting for Power-down After NMI
FA CPU Bd. Switch SW1-3 Set OFF
Ignore Soft Switch Configuration - Use
factory defaults
Flashes for 1 second
At startup
FC Waiting for Alt. Watchdog Timer Unit Stopped
FD Waiting for Updump Core Dump in process or
waiting to start
FE FLASH Programming Error
FF Unit Crashed Unit Stopped
5.3.4 Reset Switch
The reset switch (SW4) is a momentary button that lets you reset (stop
and restart) the ControlWave while you test the unit using WINDIAG
diagnostic software.
Caution
Never use the reset switch during normal operation.
5.4 WINDIAG Diagnostic Utility
WINDIAG is a software-based diagnostic tool you use to test the
performance of I/O modules, CPU memory, communication ports, and
other system components. .
