WINDIAG is a PC-based program, so the ControlWave must be
attached to and communicating with a PC running WINDIAG. Set
configuration switch SW1-8 OFF (closed) on the CPU module to
enable the diagnostic routines.
Establish communication between the ControlWave (with/without an
application loaded) and the PC with a local or network port under the
following conditions:
Turn CPU module switches SW1-3 and SW1-8 OFF to run the
WINDIAG program. Setting SW1-8 off prevents the boot project
from running and places the ControlWave in diagnostic mode.
Setting SW1-3 off causes the ControlWave to ignore soft switch
settings and use factory defaults; this sets all serial ports to 9600
baud in preparation for the diagnostic tests.
Use a null modem cable to connect RS-232 ports between the
ControlWave and the PC. Use an RS-485 cable to connect the RS-
485 ports of the ControlWave and the PC.
Note: For information on port connections and cabling, please see
Chapter 2. See Section 4.3.1 for information on communication
port defaults.
Reserve the port running a diagnostic test for exclusive use; you
cannot use that port for any other purpose during testing.
Before starting the WINDIAG program, place any critical processes the
ControlWave is handling under manual control. You cannot run
WINDIAG while the ControlWave is running applications. Set the CPU
modules switches SW2-3 and SW2-8 to OFF, and perform the
following steps:
1. Start the NetView program in OpenBSI with your current
network NETDEF file. A menu displays (similar to the one in
Figure 5-19):
