68 • iPro Case Controller I&O Manual FM V1.01 026-1738 Rev 1
MTSet Medium/Dual Temperature setpoint -40-90°
DB Deadband 1-45°
CrE Control Type Standard, Suction, Superheat Only, 
Superheat & Suction
DrE Door Enable Yes/No
Drd Door - Refrigeration ON Delay 0:00-20:00 min:sec
DrA Alarm Active Delay 0:00-20:00 min:sec
CSE Clean Switch Active Yes/No
CSd Clean Switch - Refrigeration ON Delay 0:00-60:00 min:sec
TempMode Controller is LT, MT or Dual Temp Capable LT, MT or Dual Temp
CTM Control Temperature Mode-Calculation method for locally connected 
sensors
Average/Minimum/Maximum
DrMd Door operation mode Alarm/Shutdown
CSMd Clean Switch operation mode Normal/BackOn
SSCP Superheat and suction control temperature calculation method Average/Min/Max-Local or Average/Min/
Max-Lineup
SupHtSet Superheat setpoint for EEV1-3 1-40°
Electronic Valve Parameters
EEV EEV driver Not Used/XEV20D
EEVCnt EEV Count 0-3 Valves
XEV20D-1 V1 Valve assigned to XEV20_1 Valve 1 position
EEPR or EEV1-3
XEV20D-1 V2 Valve assigned to XEV20_1 Valve 2 position
XEV20D-2 V1 Valve assigned to XEV20_2 Valve 1 position
XEV20D-2 V2 Valve assigned to XEV20_2 Valve 1 position
XEV20 Parameters
AIC01_1 XEV20_1 - Configuration of Probe 1
Not Used/Discharge 1-6/
Defrost Term 1-6/Return 1-3/Coil Out 1-3
AIC02_1 XEV20_1 - Configuration of Probe 2
AIC03_1 XEV20_1 - Configuration of Probe 3
AIC04_1 XEV20_1 - Configuration of Probe 4
Ofs01_1 XEV20_1 - Probe 1 offset
-100-100
Ofs02_1 XEV20_1 - Probe 2 offset
Ofs03_1 XEV20_1 - Probe 3 offset
Ofs04_1 XEV20_1 - Probe 4 offset
AIT01_1 XEV20_1 - Sensor Type of Probe 1 CPC Thermistor/NTC/PTC/PT1000
AIT02_1 XEV20_1 - Sensor Type of Probe 2 CPC Thermistor/NTC/PTC/PT1000
AI0304_TYPE_1 XEV20_1 - Probe 3 and Probe 4 type Resistive/Voltage/Current
AIT03_1 XEV20_1 - Sensor Type of Probe 3 CPC Thermistor/NTC/PTC/PT1000/
0-1VDC/0-5VDC/0-10VDC/0-20mA/
4-20mA
AIT04_1 XEV20_1 - Sensor Type of Probe 4
AI03_1_min
XEV20_1 - Probe 3 value at min
Selectable based on probe type
AI03_1_max XEV20_1 - Probe 3 value at max
AI04_1_min XEV20_1 - Probe 4 value at min
AI04_1_max XEV20_1 - Probe 4 value at max
Table 16-1 - iPro Parameter List
