3.3 View MPH2 System Information
1. Use the arrow keys to highlight the information icon, .
2. Press .
The MPH2 model number, serial number, firmware version, power rating and number of receptacles
display, Figure 3-4.
Figure 3-4 System information
3.3.1 System and Screen Options
On the system-information screen is a menu of icons that provides access to further system options,
network information, and LCD-screen options, Figure 3-5.
Figure 3-5 System-info and Screen-option icons
NOTE
The firmware version and other information in the figure are an examples only.
Number Description
1 Reboot/Restore-defaults icon
2 Flip screen orientation icon
3 Adjust screen contrast icon
4 System network icon
5 Up-to-previous-level icon
