Operation
Emerson
®
MPH2
™
User Manual 37
Figure 3-14 Receptacle information
Number Description
1 Receptacle-level information icon
2
Receptacle identification:
1 = MPH2 #1
A = Branch A
1 = Receptacle #1
3
Receptacle list (receptacle #1 of 5 is
selected)
