Receptacle
User Assigned Label
Receptacle
<number>
—All
Allowed characters include
alphanumeric, space,
and ~!#$_+`-={}|[]\\:;'?,.\/%^&*()@
Asset Tag 1 <empty> — All
Asset Tag 2 <empty> — All
Overcurrent Alarm Threshold 95 % M,R
Configurable per receptacle.
% calculated from maximum receptacle
current rating on nameplate.
Overcurrent Warning
Threshold
90 % M,R
Undercurrent Alarm Threshold 0 % M,R
Power Up State Restore — C,R
Restore returns receptacle power state
to last programmed state after expiration
of Power On Delay.
Power On Delay 0 seconds C,R
The delay timing begins after
measurement stability is achieved.
Power Cycle Delay 8 seconds C,R
A Power Cycle turns off power to the
receptacle for the specified delay.
Post On Delay 0 seconds C,R
Delay before RPC2 issues command to
power on receptacle.
Post Off Delay 0 seconds C,R
Delay before RPC2 issues command to
power off receptacle.
Software Over Temperature
Protection (SWOTP)
Disabled — C,R
• Unconditionally applies regardless of
locked/unlocked and loaded/unloaded
status.
• At least one temperature sensor is
required.
SWOTP Delay 10 seconds C,R
Delay required for persistent over-
temperature alarm condition before
SWOTP triggered.
SWOTP Scope Local — C,R
• Local = affects only PDU connected to
the temperature sensor that triggered
SWOTP.
• Array = affects all PDUs regardless of
temperature sensor that triggered
SWOTP.
Criticality Critical — C,R
Affects power control when a member of
a receptacle group.
Locked/Unlocked Unlocked — C,R
Affects authorization to manage power
control and behavior of SWOCP.
Table 3-1 Factory-default settings (continued)
Level Settings Default Value Units
Models
Affected Notes
