Air Pump Access PanelFigure 10-13:
4. Disconnect the air inlet and outlet tubing from the air pump.
See Figure 10-14.
Air Inlet and Outlet TubingFigure 10-14:
5. Remove the five screws (surrounded by squares in Figure 10-13) holding the air
pump to the access panel.
6. Remove the four screws holding the wiring access panel.
7. Disconnect the air pump power wires from the terminal strip. Discard the old air
pump.
See Figure 10-15.
Maintenance
Instruction Manual 81
