Logic 1 Input 2 [6414]
In this menu the second input for the Logic 1 function is
selected.
Logic 1 Operator 2 [6415]
In this menu the second operator for the Logic 1 function is
selected.
Logic 1 Input 3 [6416]
In this menu the third input for the Logic 1 function is
selected.
Logic 1 Operator 3 [6417]
In this menu the third operator for the Logic 1 function is
selected.
Logic 1 Input 4 [6418]
In this menu the fourth input for the Logic 1 function is
selected.
Logic 1 Set Delay [6419]
The activation of the output signal for the Logic 1 function
is delayed with the set value in this menu. Compare to
chapter Fig. 142 page 170.
Logic 1 Reset Delay [641A]
The reset of the output signal for the Logic 1 function is
delayed with the set value in this menu. Compare to
fchapter Fig. 142 page 170.
Logic 1 Timer Value [641B]
The actual timer value for logic 1 is viewed in this menu.
Logic 2 - 4 [642] - [644]
Refer to the descriptions for Logic 1. For default values see
chapter 15. page 227.
6414 L1 Input 2
Default: NOT1
Selection: Same as in menu DigOut 1
[541].
6415 L1 Op 2
Default: &
Selection Same as in menu L1 Op 1
[6413].
6416 L1 Input 3
Default: Run
Selection: Same as in menu DigOut 1
[541].
6417 L1 Op 3
Default: .
Selection: Same as in menu L1 Op 1
[6413].
6418 L1 Input 4
Default: Off
Selection: Same as in menu DigOut 1
[541].
6419 L1 Set Dly
Default: 0.0 s
Range: 0 - 36000.0 s
641A L1 Res Dly
Default: 0.0 s
Range: 0 - 36000.0 s
641B L1 Tmr Val
Default: 0.0 s
Range: 0 - 36000.0 s
