Enclustra Mercury+ XU8 - Product Information; Module Configuration; Mpsoc Device Types

Module Product Family Reserved Revision Product Information
Mercury+ XU8 SoC module 0x0335 0x[XX] 0x[YY] 0x0335 [XX][YY]
Table 43: Product Information
Module Configuration
Addr. Bits Comment Min. Value Max. Value Comment
0x08
7-4 MPSoC type 0 2 See MPSoC type table
(Table 45)
3-0 MPSoC device speed grade 1 3
0x09
7-6 Temperature range 0 2 See temperature
range table (Table 46)
5 Power grade 0 (Normal) 1 (Low power)
4-3 Gigabit Ethernet port count 0 2
2 RTC equipped 0 1
1-0 Reserved - -
0x0A
7-2 Reserved - -
1-0 USB 2.0 port count 0 2
0x0B
7-4 DDR4 ECC RAM (PS) size (GB) 0 (0 GB) 4 (8 GB) Resolution = 1 GB
3-0 DDR4 RAM (PL) size (GB) 0 (0 MB) 3 (4 GB) Resolution = 1 GB
0x0C
7-4 eMMC flash size (GB) 0 (0 GB) 5 (16 GB) Resolution = 1 GB
3-0 QSPI flash memory size (MB) 0 (0 MB) 7 (64 MB) Resolution = 1 MB
Table 44: Module Configuration
The memory sizes are defined as Resolution×2
(Value-1)
(e.g. DRAM=0: not equipped, DRAM=1: 1 GB,
DRAM=2: 2 GB, DRAM=3: 4 GB, etc).
Table 45 shows the available MPSoC types.
Value MPSoC Device Type
0 XCZU4CG
1 XCZU5EV
2 XCZU7EV
Table 45: MPSoC Device Types
Table 46 shows the available temperature ranges.
D-0000-454-001 53 / 60 Version 06, 18.11.2019
