Cerabar M, Deltabar M, Deltapilot M Operation
Endress+Hauser 63
6.4.7 Assignment of Transducer Blocks (CHANNEL)
Settings for the Analog Input Block
Settings for the Discrete Output Block
Process variable Transducer Block Parameter name CHANNEL parameter in
the Analog Input Block
Primary Value, a pressure, level
or flow value depending on the
measuring mode
Pressure Transducer
Block
Primary Value/
PRIMARY_VALUE
MEASURED VALUE/
PRIMARY_VALUE
1
Temperature Sensor temp. (Cerabar/
Deltapilot)/
MEASURED_TEMPERA
TURE_1
2: Cerabar and Deltapilot
Measured pressure Meas. pressure/
PRESSURE_1_FINAL_V
ALUE
3
Maximum pressure Max. meas. press./
PRESSURE_1_MAX_RE
SETABLE
4
Level before linearization Level before lin/
MEASURED_LEVEL_AF
TER_SIMULATION
5
Deltabar M:
Totalizer 1
("Flow" measuring mode)
Deltabar M:
DP_FLOW Block
Totalizer 1/
TOTALIZER_1_STRING_
VALUE TOTALIZER 1/
TOTALIZER_1_VALUE
6: Deltabar
Deltabar M:
Totalizer 2
("Flow" measuring mode)
Deltabar M:
DP_FLOW Block
Totalizer 2/
TOTALIZER_2_STRING_
VALUE TOTALIZER 2/
TOTALIZER_2_VALUE
7: Deltabar
Process variable Transducer Block Parameter name CHANNEL parameter in
the Discrete Output
Block
Min/max pressure values Pressure Transducer
Block
Reset peakhold/
RESET_TRANSMITTER_
OBSERVATION Reset
max. pressure/
RESET_TRANSMITTER_
OBSERVATION_INDEX
20
Overshoot counter of the
nominal pressure range
1)
1) Factory setting
DP_FLOW Transducer
Block
Reset Totalizer 1/
TOTALIZER_1_RESET
21
