Ecograph T, RSG35 Appendix
Endress+Hauser 103
Navigation Expert → Inputs → Universal inputs → Universal input x → Zoom start
Direct access code: 220011-0xx
Examples: Universal input 1: 220011-000; Universal input 12: 220011-011
Description If the whole value range is not used, you can configure the lower value of the required
section here. Zooming does not affect the save function.
• The zoom can also be set outside the measuring range. The only restriction is that
the start and end of the zoom may not be identical.
• If the signal or the range is changed, the zoom is corrected if it no longer fits the
measuring range.
• The zoom start can also be larger than the zoom end. The device will automatically
rotate the values on the display.
User entry Number (max. 8 digits)
Factory setting 0 (Depends on the input signal selected)
Zoom end
Navigation Expert → Inputs → Universal inputs → Universal input x → Zoom end
Direct access code: 220012-0xx
Examples: Universal input 1: 220012-000; Universal input 12: 220012-011
Description Like "Zoom start". However, enter the upper value of the required range here.
• The zoom can also be set outside the measuring range. The only restriction is that
the start and end of the zoom may not be identical.
• If the signal or the range is changed, the zoom is corrected if it no longer fits the
measuring range.
• The zoom end can also be smaller than the zoom start. The device will
automatically rotate the values on the display.
User entry Number (max. 8 digits)
Factory setting 100 (Depends on the input signal selected)
Damping
Navigation Expert → Inputs → Universal inputs → Universal input x → Damping
Direct access code: 220008-0xx
Examples: Universal input 1: 220008-000; Universal input 12: 220008-011
Description The more unwanted interference there is on the measurement signal the higher the value
that should be entered here. Result: Fast changes will be damped/suppressed.
Only visible if signal = current, voltage, resistance thermometer or thermocouple.
User entry 0 to 999.9 s
Factory setting Current, voltage: 0.0 s
Resistance thermometer, thermocouple: 0.2 s
