Technical data Liquistation CSF48
256 Endress+Hauser
15.9 Power supply
15.9.1 Electrical connection
See "Electrical connection" section.
15.9.2 Supply voltage
Depending on the version:
• 100 to 120/200 to 240 V AC ±10 %, 50/60 Hz
• 24 V DC +15/-9 %
15.9.3 Cable entry
Depending on the version:
• 1 x M25, 7 x M20 cable gland
• 1 x M25, 1 x M20 cable gland
Permitted cable diameter:
• M20x1.5 mm: 7 to 13 mm (0.28 to 0.51")
• M25x1.5 mm: 9 to 17 mm (0.20 to 0.67")
15.9.4 Mains fuse
Optional fuses:
• T10A (for 24V power supply)
• T3.15A (for 230V power supply)
• T10A (fuse for battery backup)
• For version with cCSAus approval: T4A (for cooling module)
15.9.5 Power consumption
• Device version with vacuum pump: 290 VA
• Device version with peristaltic pump: 290 VA
• Device version with sampling assembly: 290 VA
• Device version with 24 V DC power supply: 240 W
15.9.6 Power failure
• Power supply (optional): 2 x 12 V, 7.2 Ah, with additional charge controller
Replace the rechargeable batteries with type Panasonic LC-R127R2PG1.
• Real-time clock: lithium battery, type CR2032
