EnerCharge ECC 320 - Installation on the Foundation

19
Manual: Transport, Installation and Start-Up: DC CompactCharger ECC 320 ©EnerCharge GmbH
INSTALLATION
To x the ECC 320 to the foundation, proceed as follows:
5.9 Installation on the Foundation
1. Lead the power supply line through the opening in the foundation.
The supply line must protrude from the top edge of the foundation
by a sufficient length (greater than 50 centimeters).
2. Place the ECC 320 on the threaded rods of the prefab foundation
using the lifting device (see „5.7 Lifting and Lowering the ECC 320“
on page 16) and align it accordingly.
3. Open the ECC 320:
„5.8 Opening and Closing the ECC 320“ on page 18
4. Screw the ECC 320 onto the prefabricated Screw the ECC 320 to the
prefabricated foundation using the nuts and washers supplied.
5. Make sure that all eight nuts are tightened evenly.
ECC 320 successfully mounted on the foundation.
During the entire installation, the line and residual current circuit breakers for
all supply lines to the ECC 320 must be deactivated: The supply lines must be
de-energized in all cases and may only be reconnected to the mains for the nal
electrical commissioning.
• Disconnect all supply lines to the ECC 320 from the power supply.
• Apply the 5 safety rules for working on electrical equipment.
DANGER
Danger to life from electric shock
VORSICHT
Das geeignete Drehmoment liegt im Verantwortungsbereich des Betreibers
oder der Firma, welche die Montage im Auftrag des Betreibers durchführt.
• Fundament-Verschraubung mit dem geeigneten Drehmoment anziehen.
Anzugsmoment der Fundament-Verschraubung
1
2
3
4
5
>
