PREPARATION FOR INSTALLATION
> Observe all local regulations for electrical installations, re prevention and accident prevention.
> All specications for the installation of low-voltage systems according to IEC 60364-1 and IEC
60364-5-52 apply.
> For Austria, all specications for the installation of electrical systems up to AC 1000V according
to ÖVE/ÖNORM E 8001-1 apply.
> For Germany, all specications for the installation of low-voltage systems according to DIN VDE
0100 apply.
> In general, the International Standard IEC 60364 "Low-voltage electrical installations" applies.
> The specications conductive charging systems for electric vehicles - Part 23: DC power supply
systems for electric vehicles according to DIN EN 61851-23:2018 apply.
> The installation surface must have sucient strength to withstand the mechanical loads. Dimen-
sion the foundation according to the standard specications DIN EN 61851-22:2002 - see: „5.4
Foundation Strength Testing“ on page 13.
> A suciently dimensioned supply line for the power supply must be provided at the installation
site. The supply line must be laid in the ground in coordination with the pipe opening on the con-
crete foundation. If necessary, the supply line must be protected against mechanical effects in the
area in front of the foundation (by a suitable hose or pipe).
> For mechanical protection, a suitable collision protection can be implemented on site to protect
the electric car from a possible collision with the ECC 320.
> Select the location of the ECC 320 so that the charge points are easily accessible and the cable
lengths are sucient to comfortably perform charging operations.
> In principle, the ECC 320 is designed for operation in high ambient temperatures. In any case, it
must be ensured that the maximum permissible operating temperature is not exceeded by exter-
nal inuences.
> Do not set up the ECC 320 in the immediate vicinity of potentially explosive areas (e.g. gas lling
stations, etc.).
> Ventilation systems are installed in the side areas of the ECC 320. Always ensure that the ventila-
tion slots are free to ensure optimum cooling of the interior.
> Do not install the ECC 320 in areas subject to ooding and protect it from direct jets of water.
For the installation of the ECC 320, various specications regarding the
location and connection technology must be met in order to ensure safe operation.
4. Preparation for Installation
