Manual: Transport, Installation and Start-Up: DC CompactCharger ECC 320 ©EnerCharge GmbH
ATTACHMENTS
9.2 Technical Data
Table 8: Technical Data
Protection Class/Type Description
Protection class I: All electrically conductive parts of the equipment are connected with
low resistance to the protective conductor system of the fixed installation.
Charging Mode Description according to DIN 61851-1
"Mode 4"
Charging mode 4 is intended for charging with direct current (DC charging) at perma-
nently installed charging stations. The charging cable is always permanently connec-
ted to the charging stations. The safety functionalities are integrated in the charging
station. Communication between the charging station and the vehicle takes place via
the charging cable. In addition, the interlocking of the connector takes place.
Table 9: Protection Class
Table 10: Charging Mode
Charger ECC 320
20 to 240 kW Single 40 to 240 kW Dual 40 to 320 kW Single 80 to 320 kW Dual
Function DC Ladepunkt mit integrierter AC/DC-Leistungselektronik für E-Fahrzeuge mit CCS-Ladesteckdose
Housing Robustes Design (IP54/IK10)
Status Display Am 15,6 Zoll Display, via Online-Zugriff
Connection Type 1x CCS Combo-2
and/or
1x CHAdeMO
2x CCS Combo-2 1x CCS Combo-2
and/or
1x CHAdeMO
2x CCS Combo-2
Charging Voltage DC DC DC DC
Max. Current*** max. 450 A (CCS)
max. 200 A(CHAdeMO)
max. 450 A (CCS) max. 450 A (CCS)
max. 200 A(CHAdeMO)
max. 450 A (CCS)
VDC max. 150 - 1000 V
DC
150 - 1000 V
DC
150 - 1000 V
DC
150 - 1000 V
DC
Integrated AC/DC
Power Modules
1 to 12 modules Type1 2 to 12 modules Type1 1 to 8 modules Type2 2 to 8 modules Type2
Charge Points 1 (Single*) 2 (Dual**) 1 (Single*) 2 (Dual**)
No. of Charging Cables 1 2 1 2
Usability Einfach, barrierefrei
Payment Methods for
Direct Payment
Debit and credit cards, Girocard, via PIN pad, contactless payment with RFID, NFC for GooglePay
and ApplePay, membership cards, discount cards, loyalty cards, mobile Payment.
Display Easy and intuitive user guidance, display of rates and ads as well as provision of invoices
Charging Cable
CCS Combo-2 without
fluid-cooling:
Yes
User-friendliness
«««««
Communication Standard OCPP V1.6 (Open Charge Point Protocol)
Cable Length Fixed (3.5 meters) or cable pull (4.8 meters)
Temperature Ranges
Environment/Storage/Interior Temp.: - 25 to +45 degrees Celsius
Dimensions H/W/D: 1984 / 680 / 735 mm
Weight approx. 400 kilograms
AC/DC Power Modules Type1: charge power per module = 20 kW Type2: charge power per module = 40 kW
Commissioning
Activation of the charger online by EnerCharge (no on-site appointment necessary)
Operator Portal
Location-independent self-management via online access
* S = Single: Charging of one e-vehicle at a time per charging station is possible.
** D = Dual: Simultaneous charging of two e-vehicles is possible (parallel charging). The power electronics adjust the charging power
automatically. Ex.: 1 vehicle = 320 kW/1000 V
DC
, 2 vehicles = 2x 160 kW/1000 V
DC
.
*** EnerCharge offers uncooled charging cables, which ensure charging currents of up to 500 A for short periods (9 min @30 degrees Celsius/20 min @0
degrees Celsius).
