EnerCharge ECC 320 - Measures after Performed Installation

44
Manual: Transport, Installation and Start-Up: DC CompactCharger ECC 320 ©EnerCharge GmbH
INITIALIZATION
> Verify that the ECC 320 has been properly connected to the AC supply line.
> Check whether the supply lines to the ECC 320 are electrically fused.
> The protective devices inside the ECC 320s must be tested by a qualied electrician in
accordance with standard VDE 0100-600 or ÖVE/ÖNORM E8001-1:2010 (initial testing of
electrical systems).
> Verify that the charging system has been installed according to the specications in this manual:
• The charge points must be freely accessible to vehicles.
• The connected charging cables must not be under tension.
• Mechanical or other loads on the charging cables are not permitted.
> Seal installation pipes and empty conduits with suitable means.
> Check whether the base panels are mounted.
In case of improper work inside the ECC 320 and improper behavior by the operator or
technician, there are dangers due to live parts inside the housing. This can result in fatal
electric shocks when coming into contact with live parts.
• Any work on the electrical system may only be carried out by qualied electricians.
• Check and maintain ECC 320 according to the maintenance specications
(see maintenance manual).
DANGER
Fatal electric shocks inside the housing
8.6 Measures after Performed Installation
If protective conductor connections are not properly executed and
connected, leakage currents can ow through the human body. This
can result in fatal electric shocks.
• Before connecting to the supply circuit, all ground connections
must be properly made and connected.
DANGER
Fatal electric shocks due to leakage current
After the installation has been completed, the following activities must be performed:
CAUTION
CAUTION
No gap is permitted between the foundation and base panels. Unused PA screw connections must be
closed. Insects and/or other dirt particles can get inside the DC Power-Unit V2 through a gap or other
openings. Non-observance may result in damage to the device.
• Check contact surfaces between foundation and base panels for gaps.
• If necessary, seal contact surfaces between foundation and base panels with suitable means.
• Close unused PA screw connections with blank screw connections, for example.
The installation pipes and empty conduits of the cabling must be sealed after
installation has been completed. If this is not done, moisture can enter the
interior of the ECC 320 through the negative pressure of the ventilation. This
can result in damage to the device.
• Seal installation pipes and empty conduits with suitable
means inside the ECC 320.
Insects and dirt particles
Moisture in the Interior
