Manual: Transport, Installation and Start-Up: DC CompactCharger ECC 320 ©EnerCharge GmbH
WIRING DIAGRAMS ECC 320
6. Wiring Diagrams ECC 320
The connection diagram shows the necessary wiring to the ECC 320 for proper electrical installati-
on. The ECC 320 is connected to the main supply line (400 VAC). In addition, an Internet connection
via Ethernet (RJ45) is possible.
Connection
main supply line
AC/400V
Connection
Internet
ECC 320 Single
ECC 320 Dual
The ECC 320 has an integrated LTE modem.
This LTE modem establishes the Internet
connection. Optionally, the connection via
Ethernet (RJ45) is possible.
G INFORMATION
Energy supplier
