9.4 Installation of Manual Switch Disconnector
LINK to installation manual: https://support.industry.siemens.com
Model: Siemens 3VA1463-1AA32-0AA0
G INFORMATION
Tightening torque for mounting AC supply line = 28 Nm.
ATTENTION
9.5 Installation of Motorized Switch Disconnector
LINK to installation manual: https://support.industry.siemens.com
Model: Siemens 3VA9467-0HA20 MO320
G INFORMATION
Tightening torque for mounting AC supply line = 28 Nm.
ATTENTION
Fig. 54: Manual switch
disconnector
Fig. 55: Motorized switch
disconnector
