Manual: Transport, Installation and Start-Up: DC CompactCharger ECC 320 ©EnerCharge GmbH
INITIALIZATION
Table 6: ECC 320 writes
Table 7: ECC 320 reads
ECC 320 "writes"
Register Bit Address Variable Name Data Type Factor Example Description
100 Max. system power Word 1 [kW] e.g. 1 = 1,0kW Maximum power provided by the ECC 320
101 Min. system power Word 1 [kW] e.g. 1 = 1,0kW
Minimum power to which the ECC 320
can be limited.
102 Actual_Total_Power Word 1 [kW] e.g. 1 = 1,0kW Current power output
103
Readback value for
power limitation
Word 1 [kW] e.g. 1 = 1,0kW Value which was set as power limitation.
ECC 320 "reads"
Register Bit Address Variable Name Data Type Factor Example Description
200 Power Limitation ECC 320 Word 1 [kW] e.g. 1 = 1,0kW
Value of the power limitation, which is
set on the basis of the available mains
power.
201
Emergency Power
Limitation ECC 320
Word 1 [kW] e.g. 1 = 1,0kW
Value of the power limitation, if the
connection to the ModBus LAN slave bre-
aks down (connection problems).
> Example Conguration (Fig. 50):
Max. mains connection power: 100 kW
Max. power from renewable energy sources: 80 kW.
→ Max. charging power: variable 100 to 180 kW
Settings (Table 7): Register "200": 180
Register "201": 100
