Enterasys S-Series S4 Chassis Hardware Installation Guide 3-1
3
Chassis Setup
This chapter contains instructions on setting up the S4 chassis.
Electrical Hazard: Only qualified personnel should perform installation procedures.
Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion.
Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes
Personal vorgenommen werden.
For information about... Refer to page...
Required Tools 3-2
Unpacking the S4 Chassis 3-2
Installing the S4 Chassis 3-3
Attaching the Electrostatic Discharge Wrist Strap 3-12
Installing and Removing an AC Power Supply 3-13
Powering Up the S4 Chassis with AC Power Supplies 3-17
Installing and Removing an S-DC-PS Power Supply 3-18
Powering Up the S4 Chassis with S-DC-PS Power Supplies 3-22
Removing and Installing a Fan Tray 3-23
Installing and Removing an S-POE-PS Power Supply 3-24
Connecting Power to the S-POE-PS Power Supplies 3-27
LEDs 3-28
Connecting to the COM Port for Local Management 3-31
Completing the Installation 3-34
Important Notice
Read the Release Notes specific to the firmware image running in the chassis to check for any
exceptions to the supported features and operation documented in this guide.
