S-DC-PS Power Supply Specifications
Enterasys S-Series S4 Chassis Hardware Installation Guide A-3
S-DC-PS Power Supply Specifications
S-POE-PS Power Supply Specifications
S-FAN Fan Tray Specifications
Table A-4 S-DC-PS Power Supply Specifications
Item Specification
Electrical
DC Input Rated -48 to -60 VDC
Min operating input voltage: -40 VDC
Max operating input voltage: -72 VDC
Max input current: 42 A
DC Output 12 VDC
Min load: 0 A
Max load: 100 A
Max Output Power 1200 watts
Physical
Dimensions 4.1 cm x 10.16 cm x 40.64 cm (1.60" x 4.00" x 16.00")
Weight 2.29 kg (5.05 lb)
Table A-5 S-POE-PS Power Supply Specifications
Item Specification
Electrical
Input Frequency 50 to 60 Hz
Input (Voltage/Current) at Output
Power
100 to 125 Vac: 15 A at 1200 watts
200 to 240 Vac: 11 A at 2000 watts
Physical
Dimensions 4.22 cm x 10.16 cm x 35.18 cm (1.66" x 4.00" x 13.85")
Weight 2.1 kg (4.6 lb)
Inlet Type C20 inlet (accepts C19 cord)
Table A-6 S-FAN Fan Tray Specifications
Item Specification
Dimensions 27.05 cm x 2.77 cm x 42.47 cm (10.65” x 1.09” x 16.72”)
Weight 2.47 kg (5.45 lb)
