Note:
The option appears shaded in the above illustrations.
Side View with Options
(when the attachment and duplex option are installed)
947 mm
100 mm
430 mm
831 mm
160 mm
100 mm238 mm
493 mm
157 mm
100 mm
Note:
The option appears shaded in the above illustrations.
AcuLaser CX16
Front View
505 mm
100 mm
405 mm
AcuLaser CX16 Series Printer / Copier / Scanner User’s Guide
Introduction 12
