Epson AcuLaser CX16 - Part Names

Side View
765 mm
100 mm
405 mm
709 mm
100 mm234 mm
375 mm
100 mm
160 mm
Part Names
The following drawings illustrate the parts of your machine referred to throughout this guide, so
please take some time to become familiar with them.
The illustrations used in this manual show AcuLaser CX16NF as an example.
