Epson AcuLaser CX16 User Manual

No. Name Function
3
Redial/Pause key
(AcuLaser CX16NF only)
Recalls the last number dialed. Inserts a pause when a number is dialed.
For details, refer to the Facsimile User’s Guide.
4
On hook key
(AcuLaser CX16NF only)
Sends and receives transmissions with the receiver on the hook.
For details, refer to the Facsimile User’s Guide.
5
Message window
Displays settings, menus, and messages.
6
u/d keys
Moves up and down through menus, options, or choices.
7
l/r keys
Moves left and right through menus, options, or choices.
8
Select key
Press to select the setting that is currently displayed.
9
Error indicator
Indicates an error condition.
10
Back key
Clears the specified number of copies and entered text.
Press to return to the previous screen.
Press to cancel the setting that is currently displayed.
11
Keypad
Enters desired number of copies. For AcuLaser CX16NF, enters fax numbers, E-mail
addresses, and names of recipients.
12
Fax key/LED
(AcuLaser CX16NF only)
Enters Fax mode.
Lights up in green to indicate that the machine is in Fax mode.
For details, refer to the Facsimile User’s Guide.
13
Scan key/LED
(AcuLaser CX16NF only)
Enters Scan mode.
Lights up in green to indicate that the machine is in Scan mode.
For details on the Scanner functions, refer to “Using the Scanner” on page 89
14
Copy key/LED
(AcuLaser CX16NF only)
Enters Copy mode.
Lights up in green to indicate that the machine is in Copy mode.
For details on the Copy functions, refer to “Using the Copier” on page 77.
15
Start (B&W) key
Starts monochrome copying, scanning or faxing (for AcuLaser CX16NF).
16
Start indicator
Lights up in blue when copying and fax transmissions (for AcuLaser CX16NF) are
possible.
Lights up in orange when copying and fax transmissions (for AcuLaser CX16NF) are
not possible, for example, if an error has occurred.
17
Start (Color) key
Starts color copying, scanning or faxing (for AcuLaser CX16NF).
18
Stop/Reset key
Returns the settings to their defaults and stops functions.
