104

External Dimensions

Front

1 Center of lens

2 Distance from center of lens to tripod fixing point (2.9 inches [72.8 mm])

3 4.3 inches (110.5 mm)

4 4.4 inches (113 mm)

5 2.7 inches (68.5 mm)
