Vertical height when projecting on ceiling

1 9.1 inches (230 mm)

Parent topic: Technical Specifications

Projector Electrical Specifications

Rated frequency 50/60 Hz

Power supply EF21

100 to 240 V AC ±10% 1.1 - 0.5 A

EF22

24 V DC, 4.2 A
