Epson EF21 - Installing the Projector on a Tripod or Projector Stand

34
16:10 Aspect Ratio Image or Screen
Screen or image size Projection distance (1) Distance from center
of lens to base of
screen (2)
Distance from center
of lens to top of screen
(3)
140 inches 134 inches (341 cm) 0 inches (0 cm) 74 inches (188 cm)
4:3 Aspect Ratio Image or Screen
Screen or image size Projection distance (1) Distance from center
of lens to base of
screen (2)
Distance from center
of lens to top of screen
(3)
30 inches 32 inches (79 cm) 0 inches (0 cm) 18 inches (46 cm)
40 inches 43 inches (107 cm) 0 inches (0 cm) 24 inches (61 cm)
50 inches 54 inches (135 cm) 0 inches (0 cm) 30 inches (76 cm)
60 inches 64 inches (163 cm) 0 inches (0 cm) 36 inches (91 cm)
70 inches 75 inches (191 cm) 0 inches (0 cm) 42 inches (107 cm)
80 inches 86 inches (219 cm) 0 inches (0 cm) 48 inches (122 cm)
90 inches 97 inches (247 cm) 0 inches (0 cm) 54 inches (137 cm)
100 inches 108 inches (275 cm) 0 inches (0 cm) 60 inches (152 cm)
120 inches 130 inches (330 cm) 0 inches (0 cm) 72 inches (183 cm)
Parent topic: Projector Placement
Installing the Projector on a Tripod or Projector Stand
You can mount the projector on a commercially available tripod or projector stand.
• You can install the projector on a tripod that uses 1/4-20UNC size fixed screws.
• When installing the projector in a high place, be sure to install the optional security wire set
(ELPWR01) for safety purposes.
1. Turn the projector upside down.
