Epson EMP-X5 Service Manual

1-3
EMP-822/EMP-83/EMP-X5/EMP-S5
SEIKO EPSON Revision:A
1.2 Specifications
MODEL EMP-S5 EMP-X5 EMP-83 EMP-822
Specification
of main parts
LCD Size 0.55-inch
without MLA
0.63-inch
without MLA
0.63-inch
with MLA
Pixel number 480,000 dots
(800 x 600) x 3
786,432 dots
(1024 x 768) x 3
Native Resolution SVGA XGA
Aspect ratio 4:3
Projecti
on Lens
Type Digital zoom /
Manual focus
Manual zoom /
Manual focus
Zoom ratio No Optical
Zoom, Digital
Zoom (1.0-1.35)
Optical Zoom1-1.2
Lamp Type 170W UHE
Life 3000H(High Bright)/4000H(Low Bright)
Brightness
(Color mode:
Game, Zoom:
Wide)
High Brightness Mode 2000 ANSI
lumens
2200 ANSI
lumens
2600 ANSI
lumens
Low Brightness Mode 1600ANSI
lumens
1760 ANSI
lumens
2080 ANSI
lumens
Sound output 1W Monaural 7W Monaural
Operating Temperature 5°C to 35°C <41°F to 95°F> (20% - 80% humidity)
/Thermal shut down: T > 45°C
Operating Altitude 0 m to 2286 m <0 ft to 7500 ft>
(over 1500 m / 4921 ft: with High altitude mode)
Start-up period about 5 seconds (warm-up period: 30 seconds)
Cool-down period Instant off
Power Supply Voltage 100 - 240 V AC +/10%, 50/60 Hz
Power
Consumption
100-
120V
Area
(
JAPAN,
USA,
etc.)
Lamp On
248 W
Standby
(Network On)
-
5 W
Standby
(Network Off)
4.1 W
220-
240V
Area
(Europe,
etc.)
Lamp On
231 W
Standby (Network
On)
-
7 W
Standby (Network
Off)
5.8 W
Rated Voltage & Current 100 - 240 V AC 2.8 - 1.2 A 50/60 Hz
Dimension Exclude Feet (D x W x H) 245 x 327 x 92 mm
Maximum Dimension
(D x W x H)
245 x 327 x 108 mm
Weight Approx. 5.8 lbs. /
2.6 kg
Approx. 6.0 lbs. /
2.7 kg
Approx. 6.4 lbs. /
2.9 kg
Fan Noise High Brightness mode 35 dB
Low Brightness mode 28 dB

Epson EMP-X5 Specifications

General

Resolution	1024 x 768 (XGA)
Contrast Ratio	400:1
Lamp Life	3000 hours (Normal Mode), 4000 hours (Eco Mode)
Display Technology	3LCD
Zoom Ratio	1.2x
Projection Size	30 - 300 inches
Brightness	2200 lumens
Weight	2.7 kg
Inputs	Composite video, S-Video
Noise Level	35 dB (standard), 28 dB (economy)
