Epson EMP-X5 Service Manual

3-14
EMP-822/EMP-83/EMP-X5/EMP-S5
SEIKO EPSON Revision:A
3.3.4 Connection Check
Flowchart 3-4 Connection Check (1)
Before starting the checking work, be sure to turn off the power and detach the
AC cable. (refer to 3.2.3 "Cable Connection and Projector’s Status" (p. 9))
࡮
MA board CN807
Start
Switch Board
EX Fan
࡮
MA board CN702 (Lock-type connector)
࡮
MA board CN804
Shutter Switch
࡮
MA board CN704
࡮
MA board CN801
࡮
MA board CN703
࡮
MA board CN802CN803
࡮
MA board CN1400/CN1500/CN1600 (Lock-type connector)
Light Valve R/G/B
Intake Fan A,B
P/S thermistor
RC board
TH board
To Next Page
Remove
Upper Case
For more information, refer to 4.3.4 "Removing the Upper Case Unit" (p. 15) / 4.4.2 "Removing the Optical
Engine and MAB set(1) (MA Board Assy.) /IF Case" (p. 26).

Epson EMP-X5 Specifications

General

Resolution	1024 x 768 (XGA)
Contrast Ratio	400:1
Lamp Life	3000 hours (Normal Mode), 4000 hours (Eco Mode)
Display Technology	3LCD
Zoom Ratio	1.2x
Projection Size	30 - 300 inches
Brightness	2200 lumens
Weight	2.7 kg
Inputs	Composite video, S-Video
Noise Level	35 dB (standard), 28 dB (economy)
