Figure 1-7. Dimensions for Ceiling Mount (EMP-X5/S5) (mm)
7
200
30
5°
5°
5°
Ø 50
14
86.5
52
133.2
21.5
123
25°
73
15.5
51.5
141.5100.5
80
157.5
103
56.2
19
160
0.9 26.5
122
83
Unit: mm
 EMP-X5/S5
