4-20
EMP-822/EMP-83/EMP-X5/EMP-S5
SEIKO EPSON Revision:A
When installing the Shutter Switch, make sure that it is closed, as shown in the
figure below.
Figure 4-13. Correct assembly of the Shutter Switch
Stick the Shutter Sheet to the Shutter A in the position shown in the figure
below.
Figure 4-14.
Shutter Switch
Shutter A
Shutter Sheet
EMP-X5/S5’s case
Shutter A
Shutter Sheet
EMP-822/83’s case
