Epson EMP-X5 Service Manual

0-8
EMP-822/EMP-83/EMP-X5/EMP-S5
SEIKO EPSON Revision:A
4.3.3 Removing the Front Foot Unit/Rear Foot/Rubber Foot ............... 4-14
4.3.4 Removing the Upper Case Unit................................................... 4-15
4.4 Removing the Engine/Boards ................................................................ 4-25
4.4.1 Removing the Foot Detection Assy. (EMP-X5 only).................... 4-25
4.4.2 Removing the Optical Engine and MAB set(1) (MA Board Assy.)
/IF Case...................................................................................... 4-26
4.4.3 Removing the Lamp Lid Detection Switch/TH Board Assy. ........ 4-35
4.4.4 Removing the EX Fan/Inner EX Duct B ...................................... 4-37
4.4.5 Removing the Optical Engine and MAB set (2) (Optical Engine) 4-39
4.5 Removing Other Main Parts................................................................... 4-43
4.5.1 Removing the Inner EX Duct A/Intake Fan/RC Board Assy........ 4-43
4.5.2 Removing the PS Ballast Assy.................................................... 4-47
4.5.3 Removing the Lamp Fan/Speaker Unit (EMP-822/EMP83 only) 4-50
4.5.4 Removing the Lower Case.......................................................... 4-51
Chapter 5 Appendix
5.1 AS (After Service) Menu .......................................................................... 5-2
5.1.1 How To Display the AS (After Service) Menu ............................... 5-2
5.1.2 Initializing (Resetting) the AS Menu Values .................................. 5-5

Epson EMP-X5 Specifications

General

Resolution	1024 x 768 (XGA)
Contrast Ratio	400:1
Lamp Life	3000 hours (Normal Mode), 4000 hours (Eco Mode)
Display Technology	3LCD
Zoom Ratio	1.2x
Projection Size	30 - 300 inches
Brightness	2200 lumens
Weight	2.7 kg
Inputs	Composite video, S-Video
Noise Level	35 dB (standard), 28 dB (economy)
